Function introduction

HELIOS SERIES is Jassway answer to the raising demands of the Android and Windows based POS terminal. Featuring a 15.6-inch wide screen display with original LED LCD, Bezel-Free True-Flat Projective Capacitive

Touch Screen. Energy efficient Intel 1900 based processor and various I/O expansions in a beautifully crafted body. Jassway HELIOS SERIES sets a new standard with industry special motherboard which use for the professional POS.

Feature

SYSTEM
Processor	Intel Celeron J1900 (2.0 GHz) Quad-Core Processor, Fanless Intel Core I3-4030U, Dual Core, 3M Cache, 1.8Ghz Intel Core I5-4210U, Dual Core, 3M Cache, 1.7Ghz
Memory	2G Standard, DDR3, up to 8GB
Storage	32 SSD standard
OS	Windows 7,windows8.1,windows 10,POS Ready7,Android 6.0/8.0
DISPLAY
Type	9.7/10.1/15.6 inch Bezel-Free True-Flat Projective Capacitive Touch Screen
Resolution	1366*768
Brightness	350cd/m2
Touchscreen	Capacitive Touch Screen
INTERFACE
Display	1*VGA
USB	6*USB (Front 2, rear 4)
Serial	3*COM
LAN	1*Gigabit Ehernet,RJ45
Cash Drawer	1*RJ11
Audio	1Line-out, 1Mic-in
Power DC-IN	Input AC 100~240V/50~60hz,Output DC12V/5A
POWER
Power Supply	Adaptor 12V,5A
PHYSICAL&ENVIROMENTAL
Operating Temperature	Operating 0~60°
Storage Temperature	Storage-35°~75°
Dimensions(W×H×D)	400×240×400 MM
Packing Dimensions(W×H×D)	485×335×550 MM
Net Weight	7KG
Packing Weight	9 KG
Certification	CE,FCC,RoHS
Color	Black/White
OPTIONS & PERIPHERALS
2nd Display	9.7/10.1/15.6 inch LCD Display,1366*768, Optional Touchscreen
Customer Display	VFD 220 Customer Display
I/O Expansion	1×com(RJ-45 8pins)(Factory Option) 1×cash Drawer Port(Factory Option)
Storage	2.5 inch SSD 128G HDD 500GB
MSR	ISO 1,2,3 Tracks
WIFI	Support
Printer	58mm / 80mm built-in thermal printer
Optional	Camera, Fingerprint
