| Specification | |
| LCD Display | 17" TFT Panel （12.1''/15'' Option） |
| Pixel Pitch | 0.264(H) x 0.264(V) |
| Max. Resolution | Projectiive capacitive USB interface |
| Touch Screen | Projectiive capacitive USB interface |
| Brightness | Max.250 nits |
| Display Color | 16.2M / 262K colors |
| OSD(On Screen Display) | Power, Menu, Up, Down, Return |
| I/O Port | 1 x D-sub15 VGA / HDMI / USB, 1 x 12V DC in, 1 x USB(Touch Screen) |
| VESA Mount | Wall Mount & VESA 75*75mm Available |
| Power Supply | AC100~240V, DC 12V / 3A, 36watt |
| Material | Front: Bezel Zero , Back Cover: Plastic |
| Color | Black |
| Option | 3 Tracks Magnetic Reader, USB Interface |
| Physical Dimensions | 355mm(W) x 282mm (D) x 310mm (H) |
| Weight | 2.98KG |
| Temperature | Operating Temp: -5°C ~ +60°C, Storage Temp: -15°C ~ +75°C |
| Humidity |
Operating Humidity: 15%~85%, Storage Humidity: 15%~85% |
