| Windows version(With CPU fan) | |
| SYSTEM | |
| Processor | Intel® Celeron® J1900 Quad Core Processor |
| Memory | 2GB Standard, DDR3, (up to 8GB), Optional |
| Storage | Msata SSD 32GB Standard, 64GB, 128GB, 256GB, Optional |
| OS | Windows 7, Windows8.1, Windows 10, POS Ready7 |
| DISPLAY | |
| Type | 10.1'' IPS Display |
| Resolution | 1280*800 |
| Brightness | 320cd/m2 |
| Viewing Angle(CR≥10) | 160 Degree(H) |
| 160 Degree(V) | |
| Touchscreen | Projective Capacitive Touch Screen |
| INTERFACE | |
| USB | 3*USB2.0; 1* USB3.0 |
| Display | 1*VGA, 1*HDMI |
| LAN | 1*Gigabit Ehernet, RJ45 |
| Audio | 1*Line-out, 1*Mic-in |
| Power DC-IN | Input AC 100~240V/50~60hz, Output DC12V/5A |
| PHYSICAL&ENVIRONMENTAL | |
| Operating Temperature | Operating -20~70° |
| Storage Temperature | Storage -25°~75° |
| Dimensions(W×H×D) | 251 x 288 x 49(mm) |
| Packing Dimensions(W×H×D) | |
| Net Weight | 1.00KG |
| Packing Weight | |
| Color | Black |
| VESA | 75*75mm |
| Built-in Functions | |
| WIFI | Mini PCIe for Wireless LAN(Option) |
| Bluetooth | Bluetooth 4.0(Option) |
| 2D Scanner | optional |
| MSR | optional |
If you need customization, please send an email to contact us!
